RS cure XL - A Lot of Space for Many or Extra Large Printed Components

The RS cure XL is based on the proven post-exposure device, the RS cure, with high-performance LEDs, but with an extra large volume. The device is optimal for post-curing of especially large or numerous printed components. Thanks to the proven 360° luminous exposure and the modern vacuum technology, short post-exposure times are achieved with high quality. The RS cure XL is the perfect supplement to Rapid Shape´s fully automated 3D printers. The use of vacuum means, no gas is consumed during use, which significantly reduces the operating costs compared to conventional devices. The investment will amortize – depending on use – in less than one year.

Performance parameters

Volume (W × H × D) - 470 x 375 x 280 mm

Curing time - approx 6–10 minutes (depending on material)

Technology - high-power LED, multiple wavelengths, with vacuum (optional supplemental protective gas)

Control - Touchscreen

Connections - WiFi/LAN

Power Supply - 110V/60Hz, 230V/50Hz, max. 1150W

Dimension (W × H × D) - 650 x 1050 x 800 mm

Weight ~ 150 kg
